Oriented silicon steel cold rolled silicon steel sheet from China factory, suitable for transformer core plate
Electrical steel, also called lamination steel, silicon electrical steel, silicon steel or transformer steel, is a material used to produce certain magnetic cores, such as stators and rotors in transformers and motors. Electrical steel is also an indispensable material for the power, electronics and military industries.
Grain-oriented electrical steel usually has a silicon level of 3% (Si:11Fe). It is processed in such a way that the optimal properties are developed in the rolling direction, due to a tight control (proposed by Norman P. Goss) of the crystal orientation relative to the sheet. The magnetic flux density is increased by 30% in the coil rolling direction, although its magnetic saturation is decreased by 5%. It is used for the cores of power and distribution transformers, cold-rolled grain-oriented steel is often abbreviated to CRGO.
Transformer automatic movable automatic trolley core tilting links
Iron transformer core forming machine
Powe transformer body incline platform
Ilicon split reactor magnetic disk core production links
CCA plane transform vehicle body assembly frame
Transformer Amorphous Core Annealing Furnace
